. 2-wire and 4-wire resistance measurement.
. Capacitance measurement up to 100mF.
. Decibel measurement with selectable reference impedance from 1~2400Ω.
. Measurement data hold, relative value measurement, maximum/minimum/average value measurement.
. Selectable manual or auto range.
. Measurement comparison function: preset limit range (upper/lower limit), judging3
whether the measurement is out of range according to the result, and audio alarm.
. Trigger input and measurement completion output functions.
. 8 grades of thermocouple measurements: K, E, J, T, B, S, N, R, with manual RJ compensation.
. Selectable temperature display units: °C or °F.
. Remote operation via RS-232 interface, USB interface, and LAN interface.
. Support SCPI programming language and multiple command sets.
. Panel calibration technology: no need to open the case for calibration.
| Technical Data | Measuring Range | Resolution | Accuracy | Grade |
| DCV | 200mV | 1uV | 0.012+0.004 |
|
| 2V | 10uV | 0.012+0.003 |
|
| 20V | 100uV | 0.012+0.004 |
|
| 200V | 1mV | 0.015+0.003 |
|
| 1000V | 10mV | 0.015+0.003 |
|
| ACV | 200mV | 1uV | 1.5+0.1 (20Hz～45Hz) 0.2+0.08 (45Hz～100Hz) 0.2+0.08 (100Hz～10kHz) 1.0+0.05 (10kHz～30kHz) 2.0+0.1 (30kHz～50kHz) 3.0+0.3 (50kHz～100kHz) |
|
| 2V | 10uV |
|
| 20V | 100uV |
|
| 200V | 1mV |
|
| 750V | 10mV | 1.5+0.1 (20Hz～45Hz) 0.2+0.08 (45Hz～100Hz) 0.2+0.08 (100Hz～10kHz) |
|
| DCA | 200uA | 0.001uA | 0.03+0.01 |
|
| 2mA | 0.01uA | 0.03+0.01 |
|
| 20mA | 0.1uA | 0.02+0.006 |
|
| 200mA | 1uA | 0.03+0.01 |
|
| 2A | 10uA | 0.05+0.02 |
|
| 10A | 100uA | 0.25+0.05 |
|
| ACA | 200uA | 0.001uA | 1.0+0.1 (20Hz～45Hz) 0.5+0.05 (45Hz～2kHz) 0.8+0.05 (2kHz～10kHz) 1.2+0.15 (10kHz～30kHz) |
|
| 2mA | 0.01uA |
|
| 20mA | 0.1uA |
|
| 200mA | 1uA |
|
| 2A | 10uA | 2.0+0.5 (20Hz～45Hz) 0.5+0.05 (45Hz～2kHz) 1.2+0.15 (2kHz～5kHz) |
|
| 10A | 100uA |
|
| Resistance | 200Ω | 1mΩ | 0.03+0.01 |
|
| 2kΩ | 10mΩ | 0.03+0.003 |
|
| 20kΩ | 100mΩ | 0.03+0.003 |
|
| 200kΩ | 1Ω | 0.03+0.003 |
|
| 2MΩ | 10Ω | 0.03+0.02 |
|
| 20MΩ | 100Ω | 0.55+0.02 |
|
| 100MΩ | 1kΩ | 5.5+0.04 |
|
Capacitor
| 10nF | 1pf | 2+0.5 |
|
| 100nF | 10pf | 1+0.5 |
|
| 1µF | 100pf | 1+0.5 |
|
| 10µF | 10nF | 2+0.5 |
|
| 100µF | 100nF | 2+0.5 |
|
| 1mF | 10nF | 2+0.5 |
|
| 10mF | 1µF | 5+0.5 |
|
| 100mF | 10µf | 5+0.5 |
|
| Frequency | 3~5 Hz | 0.1mHz~100mHz | 0.1+0.01 |
|
| 5~10 Hz | 0.05+0.003 |
|
| 10~40 Hz | 0.03+0.003 |
|
| 40~100k Hz | 0.01+0.003 |
|
| 100k~10M Hz | 0.05+0.003 |
|
| Thermocouple | -200~0℃, 0~1370℃ | 0.1℃ | 1.2℃, 0.8℃ | K |
| -200~0℃, 0~1000℃ | 1.5℃, 0.9℃ | E |
| -200~0℃, 0~1200℃ | 1.0℃, 0.7℃ | J |
| -100~0℃, 0~400℃ | 1.0℃, 0.7℃ | T |
| -200~0℃, 0~1300℃ | 1.5℃, 0.9℃ | N |
| -40~500℃, 500~1760℃ | 1℃ | 1.8℃, 1.5℃ | R |
400~800℃, 800~1000℃, 1000~1800℃ | 2.2℃, 1.8℃, 1.4℃ | S |
| RTD | -200~0℃, 0~400℃, 400~850℃ | 0.1℃ | 0.5℃, 0.7℃, 0.8℃ | Pt100 |
400~800℃, 800~1000℃, 1000~1800℃ | 0.2℃, 0.3℃, 0.4℃ | Pt1000 |
| Diode | 2V |
| 0.1+0.1 |
|
| Continuity | 2kΩ |
| 0.15+0.2 |
|
| Input impedance | 10MΩ (200mV, 2V, 20V, 200V, 1000V) | 10GΩ (200mV, 2V) |
| Power source | 250V±10% AC, Frequency: 50Hz or 60Hz |
| Dimensions | 260×110.5×313 |
| Weight | 4kg |
